Description:

8 Channels (one Way) Line-Level Balanced Audio with Phoenix Style Connectors, Balanced Audio Over Fiber Transmitter Receiver to 20 Km SM Fiber or 500 Meters MM Fiber

Features:

1). 8 Channels balanced audio signal over 20Km+ on SMF or 500 meters on MMF

2). Supports   16-bit digitally encoded broadcast quality balanced audio

3). Easy stand-alone or rack-mount installation.

5). Plug and Play design ensures adjustment-free installation and operation, and optical adjustments are never required.

6). LED indicators are provided to instantly monitor the system operating status.

Specifications

Opitcal

Wavelength:   1310nm

Output Power: -14~ -8dBm

Optic fiber: 50/125u multimode，62.5/125u multimode，9/125u single mode

Rx sensitivity: -30dBm

Optical connector: 1 x FC (default), ST/SC (optional)

Distance:   0~500M (MMF)   /   0~20KM(SMF)

Audio

Balanced Audio Number of Channels:   8

Connector:   Standard terminal lead

Input / Output Impedance:   10K Ohm

Input capacitance LINE inputs:   10 pF

Max input/output voltage:   +4 dBu (1.228 Volts)

Frequency Response:   20 Hz～24kHz @±3dB

Sample Rates From:   48kHz

SNR:   > 80dB

Electrical & Mechanical

Input Power Requirements:   DC 5V@2A

Power Adapter:   AC 90V~240V

Power Consumption: < 3W

Stand-Alone Dimensions: 175mm × 154mm × 30mm

Environmental

Operating Temperature: -20°C ~ +75°C

Storage Temperature: -40°C ~ +85°C

Relative Humidity: 0% ~ 95% (non-condensing)

MTBF: >100,000 hours

Application:

Rental, Staging, Theater, Stadiums, Theme Parks, Broadcast/Studio, CCTV audio and Professional AV applications etc

Diagram:

Sell on Amazon, worldwide delivery:

Part Number	link on amazon.com	QR codes of this amazon link
BY-Audio-343: 8 Ch 1 way over 1 fiber	https://www.amazon.com/ dp/B079NCVP6X
